NEW ONBOARD COMPUTER FUNCTION

New Onboard computer function with the following information:



  • Total fuel consumption
  • Average fuel consumption
  • Real time fuel consumption
  • Estimated fuel range

    Access the "Sensors and calibration" menu > "Fuel consumption control" to perform the configuration:





To restart the counter go to the "Tools" top menu > "Fuel":





To configure the units of measure of the information, go to the side quick access panel and click the "Measurement Units" menu



The information can also be activated in the internal Datalogger, to activate, access the menu "Other functions" > "Individual channel options":




Estimated power and torque calculation based on fuel consumption and advanced injector flow calculation, shown in real time on the screen and recorded on the internal datalogger.



NEW CAN OEM OPTION FOR RENAULT SANDERO RS



New CAN OEM option for Renault Sandero RS with the following sensors:



    • Individual wheel speed
    • Engine temperature
    • Air temperature
    • Brake pedal
    • Clutch pedal
    • A/C button
    • Map selection button (using stock Sport button)
    • High beam
    • Low beam





NEW CAN OEM OPTION FOR ABS BOSCH MOTORSPORT 500KBPS





    • Individual wheel speed



AUTOMATIC TRANSMISSION CONTROL UPDATE


Automatic transmission control function received a few updates like:



  • Possibility to configure solenoid activation only during gear shift

  • Gear based compensation time for oil pressure control during gear shift





NEW OPTION FOR GENERIC DUTY CYCLE CONTROL OUTPUT





    • Gear and engine RPM based

    • Gear elapsed time based



NEW OPTION FOR PROGRESSIVE NITROUS CONTROL #1 AND #2





    • Gear and engine RPM based

    • Gear elapsed time based

    • MAP based



NEW DEDICATED FUEL TANK LEVEL ANALOG INPUT





Fuel tank level input was updated with a dedicated feature that now uses averaged values to give the user a smooth reading.



NEW OPTION TO CHOOSE DRIVESHAFT RPM OR WHEEL SPEED (TRACTION OR DRAG) AS REFERENCE FOR GEAR CHANGE DETECTION





To choose traction or drag speed, go to the "Sensors and Calibration" menu > "Gear change detection":



NEW OPTION TO ENABLE ELECTRIC FAN 1 AND 2 ONLY WITH ENGINE RUNNING





Access the new option in the menu "Other functions" > "Thermatic fan:



ADDED NEW OPTION FOR SHIFT LIGHT OUTPUT ACTIVATION: 0V OR 12V





To set the shift light output drive voltage, go to the "Other functions" menu > "Shift light":



NEW OPTION TO ACTIVATE A/C USING A BUTTON ON THE TOUCHSCREEN





To configure the type of air conditioning activation, go to the menu: "Other functions" > "Air conditioning":



NEW OPTION TO APPLY ACCELERATION FUEL ENRICHMENT IN THE SECONDARY BANK OF INJECTORS





To enable acceleration fuel enrichment on pump on bank B, go to the menu: "Engine settings" > "Fuel Injection":



NEW WARNING ALERT OUTPUT



Added option to trigger an output whenever a warning/alert comes up on the ECU.

In order to setup the new option, go to the menu: "Alert settings" and then remember to setup an output to trigger your warning light:



NEW TIME BASED INDIVIDUAL IGNITION AND FUEL TRIM





  • Time based Individual fuel trim (Primary):







  • Time based Individual Ignition trim:



GENERAL IMPROVEMENTS


• New option to use blue output for eGate control (using FuelTech Dual Power Driver);

• New option for side LED's based on the automatic transmission control solenoids activation;

• Added new option to configure trigger detection voltage when using hall effect crank and cam sensor (must use Custom option);

• Updated fuel flow calculation not requiring the use of fuel return sensor;

• Added Primary and Secondary Injection time data to the simplified FTCAN 2.0 protocol;

• Added Oil Temperature and Transmisssion Temperature data to the FTCAN 2.0 protocol;

• New Lock up overide button;

• Improvement of the Rev limiter strategy;

• New option for Gear Control Management function (GCM) to return to N (Neutral) using only Interlock button;





CORRECTIONS


WINDOWS DEFENDER SMARTSCREEN WARNING MESSAGE

After executing the program, Windows Defender SmartScreen may display a warning message when installing FT Manager.

Here are the steps to follow to install FT Manager if this happens to you:

A - Click More info link:




B - Click the Run anyway and wait for the installation to finish:
